Product Overview
Magnetic wireless temperature sensor is a temperature sensor featuring ultra-low power consumption and high accuracy. It consists of a temperature sensor, signal modulation and amplification device, logic control circuit, wireless communication circuit, lithium battery, and antenna. This sensor uses ultra-low power wireless communication to transmit the collected temperature data to the wireless temperature measurement host via a wireless network.
This temperature sensor features single-channel temperature detection and uses a magnetic mounting method for easy installation. It is primarily used to measure the temperature of the surface or contacts of high-voltage energized objects, such as the operating temperature of industrial production equipment, high-power motors, exposed contacts in high-voltage switchgear, busbar connections, outdoor disconnect switches, and transformers.
Main technical parameters
|
Temperature measurement range
|
-40～+200℃
|
|
Measurement accuracy
|
±1℃
|
|
Thermistor
|
PT1000
|
|
Temperature Sampling frequency
|
Default 10 seconds
|
|
Communication methods
|
LORA
|
|
Mireless frequency
|
470-510MHz
|
|
Wireless transmission distance
|
≤800 meters
|
|
Battery lifespan
|
5-8 years
|
|
Installation method
|
Magnetic fixation
|
|
General
|
105mm
|
|
External dimensions
|
85mm*85mm*34mm,
|
|
Installation location
|
Outdoor isolating switches, wall-penetrating cable clamps, transformer inlet and outlet terminals, outdoor flexible copper busbar connections, and other components.
|
