Product Introduction
Broadband carrier KSF710L is an industrial-grade bandwidth power line carrier communication device based on IEEE P1901, adopting OFDM modulation and demodulation technology, and conforming to the European Union's EN-50561 standard specification. It uses the existing power lines or slip contact cord as the information transmission medium for high-speed and long-distance transmission of data, and has the features of high communication rate, bi-directional transparent transmission, good stability of transmission, and strong scalability.
Broadband Carrier KSF710L is a 100Gbps high bandwidth long-distance communication device with self-routing algorithm, automatic network formation, built-in LDPC error correction codec, AES-128bit encryption algorithm, fully transmissible data, plug and play. Hundred megabit bandwidth, communication rate of 10Mbps/100Mbps adaptive bandwidth. Long transmission distance, power line point-to-point transmission distance up to 500 metres, coaxial cable transmission distance up to two or three thousand metres. Networking mode supports bus, star, tree, and hybrid network topology.
Broadband carrier KSF710L is an industrial standard, internal integrated filtering function, suitable for AC85-300V or DC100-400V power line or sliding contact line carrier communication, make full use of the existing power line network, do not need to rewire,optimize the cumbersome wiring of network networking to the greatest extent. Used in all kinds of video transmission systems and industrial control systems, such as inspection robots, logistics sorting system, intelligent overhead crane, railway communication monitoring system, mine monitoring system, new wind energy, new energy power station, industrial video monitoring and so on.
